product introduction:
tissue absorption tester (t 049) is a special instrument for measuring the water absorption capacity of toilet paper, kitchen paper towel and toilet paper. the instrument consists of standard stainless steel basket, automatic lifting platform, draining device, automatic weighing device, etc.
main performance:
1. the samples that can automatically complete the test process are free to fall into the water. after being soaked for a period of time, the samples are taken out and drained at an inclined angle, and the water absorption performance indexes of the samples are measured.
2. adopt servo motor and high-precision ball screw drive, with precise stroke control;
3. adopt color lcd touch screen display and real-time data display;
4.use human-machine interaction interface, with simple parameter setting and convenient operation;
5.collect and process test data automatically;
6.it is equipped with thermal printer to print test results at any time;
7.provide standard stainless steel basket.
reference standard:
gb/t 24328.6 卫生纸及其制品 第6部分：吸水时间和吸水能力的测定 篮筐浸没法
gb/t 26174《厨房纸巾》
gb/t 24455《擦手纸》
technical parameters:
standard basket quality:（3.0±0.1）g
sample release height：（25±5）mm
soak time of sample：（30±1）s
draining time：（60±1）s
drain angle：30°
resolution of timing device：0.01s
power supply：220v/50hz
power：0.8kw
dimension, mm：l400mm×w400mm×h700mm
net weight：20kg
